SMD1515 High Resolution LED Screen , 80*160 Dot matrix Led Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE,ROHS,PSE,UL |
| Model Number: | P2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | flight case |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
|
Detail Information |
|||
| Color: | FULL COLOR | Pixel Pitch: | P2 |
|---|---|---|---|
| LED Type: | SMD1515 | Drive Type: | 1/20 Scanning |
| IP Level: | IP31 | Panel Size: | 320*160mm |
| Resolution: | 80*160 | Cabinet Size: | Customized |
| High Light: | SMD1515 High Resolution LED Screen,SMD1515 Dot Matrix Led Display,80*160 Dot Matrix Led Display |
||
Product Description
P2 Die Casting Rental Small Pixel 80*160 Dot Matrix Led Display Video Wall Module 1/20 Scan
DL LED is a professional LED Signs manufacturer for more than 10years history. Our LED Window Display Signs with high brightness, and user-friendly software including PC and APP version which makes you free to update the content everyday. The wireless LED scrolling sign would show the ultra bright text to help you attract your client eyes to increase business. Also our illuminated window signs is with UL certified power supply, which ensure the most durable quality for the LED Board .
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.
Module Specification:
| Dimensions(WxH) | 320×160mm | Resolution(WxH) | 160×80dots |
| Pixel Pitch(mm) | 2 | Pixel Density | 250000 pixels/m2 |
| Pixel Configuration | SMD 2121 | ||
| LED parameters |
R WL(620-625NM) IV:(600-800mcd) |
G: WL:(520-524nm) IV:(1400-1800mcd) |
B:WL:(470-472nm) IV :(800-880mcd) |
 |
|||
Cabinet Specification:
| Dimensions (WxH) | 640mm x 480mm | Module Quantity | 6 |
| Physical Resolution(WxH) | 320 x240 dots | Physical Pixels (Total) | 76800 |
| Weight/Cabinet | 8KG | Material | Die-Castiing aluminum |
|
|||
LED Display Parameter:
1.Technical Support
(a) we provide free technical support, which includes operation training and maintenance training in the factory
(b) we can send our engineers to your country after negotiation
2, Maintenance and Consultation
(a) we provide full maintenance for a lifetime and only charge the raw material cost
(b) we also provide lifetime consultation through Email, SMS, Phone call, etc.
3, Documents and Certificates
(a) we provide all necessary user's manual, software, test report, CAD drawing, etc.
(b) we can also provide all kinds of certificates, such as CE, RoHS etc.
.
