320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ

Quality 320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ factory
Quality 320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ factory
Quality 320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ factory
Quality 320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ factory
Quality 320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ factory
Product Specification
Place of Origin: CHINA
Brand Name: DL
Certification: CE,ROHS,PSE,UL
Model Number: P2
Minimum Order Quantity: 1PCS
Price: Negotiate
Payment Terms: T/T, Western Union,
Product Details
Highlight:

320mm*160mm Indoor Led Display Panel

,

3840HZ Indoor Led Display Panel

,

3840HZ indoor led panel
Pixel Pitch: P2
Color: Full Colour
Module Size: 320mm*160mm
Panel Size: 640mm*640mm
Brightness: 1000-1300cd/sqm
Input Voltage: 110-230V
Drive Type: 1/40 Scanning
Life Span: 100000hours
Product Description

3840HZ SMD1515 P2 Indoor Led Module 320mm*160mm Led Display Panel P2



1. High refresh rate: 3840Hz, which can make clearer and vivider piture,No chromatic

2. Seamless Assembly:Made through CNC,Assembly accuracy 0.1mm

3. Easy to move and fast installation: Light weight, Die-casting Aluminum Cabinet,Lighter and Slimmer

4. Fully-front service, very suitable for wall-mounted installation

5. Option for rental events solution



Module Specification:

Dimensions(WxH) 320×160mm Resolution(WxH) 160×80dots
Pixel Pitch(mm) 2 Pixel Density 250000 pixels/m2
Pixel Configuration SMD 2121
LED parameters

R WL(620-625NM)

IV:(600-800mcd)

G: WL:(520-524nm)

IV:(1400-1800mcd)

B:WL:(470-472nm)

IV :(800-880mcd)
320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ



Cabinet Specification:

Dimensions (WxH) 640mm x 480mm Module Quantity 6
Physical Resolution(WxH) 320 x240 dots Physical Pixels (Total) 76800
Weight/Cabinet 8KG Material Die-Castiing aluminum
320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ



LED Display Parameter:

item
value
Pixel Pith
2mm
Module Size
320mm×160㎜
Module Resolution
160×80 dots
Cabinet Size
640mm×480mm×58mm
Cabinet Resolution
320×240 dots
Resolution
250000 dots/㎡
Brightness
≤800cd/㎡
Refresh Frequency
1920Hz
Grey Level
16bits
Driving Mode
Constant current
Avg Consumpation
260W/㎡
Max. Consumpation
650w/㎡
Input voltage
AC110-240
Viewing Distance
2-60m
viewing Angle
Horizontal 140deg. Vertical 140deg.
Lifetime at 50% brightness
100,000 hours
Operating temperature
-20℃ ～ +55℃
Operating humidity
10％ ～ 90％
Source compatibility (with video processor)
HDMI, HDSDI, SDI, VGA, RJ45, YC



320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ





320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ



Product Description



1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.



320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ
