Product Details:

Place of Origin: CHINA
Brand Name: DL
Certification: CE,ROHS,PSE,UL
Model Number: P2

Payment & Shipping Terms:

Minimum Order Quantity: 1PCS
Price: Negotiate
Packaging Details: flight case
Delivery Time: 5-15days
Payment Terms: T/T, Western Union, MoneyGram
Get Best Price Contact Now

Detail Information

Color: FULL COLOR Pixel Pitch: 2mm
LED Type: SMD1515 (3in1) Drive Type: 1/32 Scanning
IP Level: IP31 Control System: Novastar /Linsn/Huidu Cards
Cabinet Size: Customized LED Chip: Smd 2121 Epistar Nation Star Cree Nichia
High Light:

IP31 Large Video Wall Displays

,

SMD1515 Large Video Wall Displays

,

SMD1515 large video wall

Product Description

Full Color Hd Display P2 P2.5 P3 P3.91 P4 Indoor Outdoor Led Screen Large Video Wall Display LED



1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.

2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.





Module Specification:

Dimensions(WxH) 320×160mm Resolution(WxH) 160×80dots
Pixel Pitch(mm) 2 Pixel Density 250000 pixels/m2
Pixel Configuration SMD 2121
LED parameters

R WL(620-625NM)

IV:(600-800mcd)

G: WL:(520-524nm)

IV:(1400-1800mcd)

B:WL:(470-472nm)

IV :(800-880mcd)

SMD1515 IP31 Large Video Wall Displays Horizontal Vertical 140 Degree 0



Cabinet Specification:

Dimensions (WxH) 640mm x 480mm Module Quantity 6
Physical Resolution(WxH) 320 x240 dots Physical Pixels (Total) 76800
Weight/Cabinet 8KG Material Die-Castiing aluminum
SMD1515 IP31 Large Video Wall Displays Horizontal Vertical 140 Degree 1



LED Display Parameter:

item
value
Pixel Pith
2mm
Module Size
320mm×160㎜
Module Resolution
160×80 dots
Cabinet Size
640mm×480mm×58mm
Cabinet Resolution
320×240 dots
Resolution
250000 dots/㎡
Brightness
≤800cd/㎡
Refresh Frequency
1920Hz
Grey Level
16bits
Driving Mode
Constant current
Avg Consumpation
260W/㎡
Max. Consumpation
650w/㎡
Input voltage
AC110-240
Viewing Distance
2-60m
viewing Angle
Horizontal 140deg. Vertical 140deg.
Lifetime at 50% brightness
100,000 hours
Operating temperature
-20℃ ~ +55℃
Operating humidity
10% ~ 90%
Source compatibility (with video processor)
HDMI, HDSDI, SDI, VGA, RJ45, YC



SMD1515 IP31 Large Video Wall Displays Horizontal Vertical 140 Degree 2SMD1515 IP31 Large Video Wall Displays Horizontal Vertical 140 Degree 3

SMD1515 IP31 Large Video Wall Displays Horizontal Vertical 140 Degree 4



1.Technical Support
(a) we provide free technical support, which includes operation training and maintenance training in the factory
(b) we can send our engineers to your country after negotiation
2, Maintenance and Consultation
(a) we provide full maintenance for a lifetime and only charge the raw material cost
(b) we also provide lifetime consultation through Email, SMS, Phone call, etc.
3, Documents and Certificates

(a) we provide all necessary user's manual, software, test report, CAD drawing, etc.
(b) we can also provide all kinds of certificates, such as CE, RoHS etc.

.

SMD1515 IP31 Large Video Wall Displays Horizontal Vertical 140 Degree 5

FQA:

Q1. Can I have a sample order for the LED display?

A: Yes, we welcome sample order to test and check quality. Both for the module or the whole screen.

Q2. What about the lead time?

A: Order less than 100 square meters led time to take 15 working days

Q3. Do you have any MOQ limit for LED display order?

A: Low MOQ, 1 square meter or a module checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We mostly accept the FOB train term, but we can help you order and arrange a shipping agent. It usually takes 20 30 days on the sea. a few days for customs clearance
