128*128mm High Resolution LED Screen 250000 dots for Advertising
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE,ROHS,PSE,UL |
| Model Number: | P2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | flight case |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
|
Detail Information |
|||
| Pixel Pitch: | P2 | Color: | Full Colour |
|---|---|---|---|
| Panel Size: | 640x480 | Panel Pixel: | 320x240dots |
| Pixel Density: | 250000dots | Input Voltage: | 110-230V |
| Refresh Rate: | 3840 | Function: | Video |
| High Light: | 128*128mm High Resolution LED Screen,250000 Dots High Resolution LED Screen,250000 Dots Advertising LED Screen |
||
Product Description
Full Color Video Advertising Led Display P2 Indoor Rgb 128*128mm High Definition Smd Led Module
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.
Module Specification:
| Dimensions(WxH) | 320×160mm | Resolution(WxH) | 160×80dots |
| Pixel Pitch(mm) | 2 | Pixel Density | 250000 pixels/m2 |
| Pixel Configuration | SMD 2121 | ||
| LED parameters |
R WL(620-625NM) IV:(600-800mcd) |
G: WL:(520-524nm) IV:(1400-1800mcd) |
B:WL:(470-472nm) IV :(800-880mcd) |
 |
|||
Cabinet Specification:
| Dimensions (WxH) | 640mm x 480mm | Module Quantity | 6 |
| Physical Resolution(WxH) | 320 x240 dots | Physical Pixels (Total) | 76800 |
| Weight/Cabinet | 8KG | Material | Die-Castiing aluminum |
|
|||
LED Display Parameter:
Product Description
1. Convenient Usage
2. High Quality
SMD2121 or SMD1515 LED Chip, wide viewing angle, perfectly matching with events,exhibition and concerts etc.
3. Super Light and Slim
The cabinet is light in weight so it's easy for you to install it and convenient for delivery.
4. High Refresh Rate
The refresh rate is more than 38400 HZ so the screen picture is clear wihtout flicker and distortion, thus to protect your eyes
5. Less Noise Design
The air fan free to eliminate noise; Al Materials can improve the heat emission, meeting the demands of less noise in the indoor occasions.
