P2 Front Service Led Display , RGB LED Video Wall 160000dots
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE,ROHS,PSE,UL |
| Model Number: | P2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | flight case |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
|
Detail Information |
|||
| Pixel Pitch: | 2 | Color: | RGB COLOR |
|---|---|---|---|
| Application: | Indoor | Panel Size: | 640mm*480mm |
| Panel Pixel: | 320x240dots | Pixel Density: | 160000dots/sqm |
| Input Voltage: | 100-240V | Refresh Rate: | 3840Hz |
| High Light: | P2 Front Service Led Display,160000dots RGB LED Video Wall,160000dots Front Service Led Display |
||
Product Description
Factory Customized Panel Size Full Color HD RGB LED Display LED Video Wall Front Service Led Screens Indoor Advertising
Our Goal is to provide our customers with the best LED solutions for their needs,
with many years of LED Production experiences.
Add a welcome charming modern touch to your Advertising with this high-quality Led Sign!
led advertising message signs is widely used in shopping malls, hairdressers,
beauty chain stores, restaurants, bars, parking lots,
entertainment venues ect and suitable for all kinds of indoor and outdoor commercial billboards.
Module Specification:
| Dimensions(WxH) | 320×160mm | Resolution(WxH) | 160×80dots |
| Pixel Pitch(mm) | 2 | Pixel Density | 250000 pixels/m2 |
| Pixel Configuration | SMD 2121 | ||
| LED parameters |
R WL(620-625NM) IV:(600-800mcd) |
G: WL:(520-524nm) IV:(1400-1800mcd) |
B:WL:(470-472nm) IV :(800-880mcd) |
 |
|||
Cabinet Specification:
| Dimensions (WxH) | 640mm x 480mm | Module Quantity | 6 |
| Physical Resolution(WxH) | 320 x240 dots | Physical Pixels (Total) | 76800 |
| Weight/Cabinet | 8KG | Material | Die-Castiing aluminum |
|
|||
LED Display Parameter:
Product Description
1. Convenient Usage
2. High Quality
SMD2121 or SMD1515 LED Chip, wide viewing angle, perfectly matching with events,exhibition and concerts etc.
3. Super Light and Slim
The cabinet is light in weight so it's easy for you to install it and convenient for delivery.
4. High Refresh Rate
The refresh rate is more than 38400 HZ so the screen picture is clear wihtout flicker and distortion, thus to protect your eyes
5. Less Noise Design
The air fan free to eliminate noise; Al Materials can improve the heat emission, meeting the demands of less noise in the indoor occasions.
