0.48kg Led Display Video Wall , P2.5 Led Panel For Tv Studio
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE,ROHS,PSE,UL |
| Model Number: | P2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | flight case |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
|
Detail Information |
|||
| Pixel Pitch: | 1.25/1.875/2/2.5 | Color: | RGB COLOR |
|---|---|---|---|
| Drive Mode: | 1/32 | Module Weight: | 0.48 |
| LED Chip: | SMD2121 | Brightness: | 1200cd |
| Display Function: | Animation/Graphics/Video | Life Span: | 100000 Hours |
| High Light: | 0.48kg Led Display Video Wall,0.48kg P2.5 Led Panel,Tv Studio P2.5 Led Panel |
||
Product Description
Indoor HD P2.5 Led Panel Led Screen Led Video Wall For Tv Studio
Our Goal is to provide our customers with the best LED solutions for their needs,
with many years of LED Production experiences.
Add a welcome charming modern touch to your Advertising with this high-quality Led Sign!
led advertising message signs is widely used in shopping malls, hairdressers,
beauty chain stores, restaurants, bars, parking lots,
entertainment venues ect and suitable for all kinds of indoor and outdoor commercial billboards
Module Specification:
| Dimensions(WxH) | 160x160mm | Resolution(WxH) | 64x64dots |
| Pixel Pitch(mm) | 2.5 | Pixel Density | 147456 pixels/m2 |
| Pixel Configuration | SMD 2121 | ||
| LED parameters |
R WL(620-625NM) IV:(600-800mcd) |
G: WL:(520-524nm) IV:(1400-1800mcd) |
B:WL:(470-472nm) IV :(800-880mcd) |
 |
|||
Cabinet Specification:
| Dimensions (WxH) | 480mm x 480mm | Module Quantity | 9 |
| Physical Resolution(WxH) | 192 x192 dots | Physical Pixels (Total) | 36864 |
| Weight/Cabinet | 8KG | Material | Die-Castiing aluminum |
|
|||
LED Display Parameter:
| Pixelpitch(mm) | P2.5 |
| LED Encapsulation | SMD2121 |
| Density(dot/m2) | 147456 |
| Module size LxH mm | 160*160mm |
| Module Resolution | 64*64dot |
| Cabinet Size | 480*480mm |
| Cabinet resolution | 192*192dot |
| Viewing Distance | 3-8m |
| viwe angle(H) | 140° |
| view angle(V) | 140° |
| Brightness (cd/m²) | 1500 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/16scan |
| MTBF | 100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| IP rating | IP55/IP42 |
Product Description
1.High bright 3 in 1 LED SMD lamps with best plastic package suite are not easy to be damaged and ensures
the best viewing angle.
2.Constant current chip driving reduces the power consumption and prompts the stability, the simple modular design is low cost and easy to maintain.
3.Can undertake single point, single lamp maintenance,the cost is low.
4.Neat appearance,light weight,small size and safe 5V low voltage power supply system all make the module
more attractive.
5.Due to its locating holes and 4 in bracket design,it can be used on indoor big screen.
6.Besides,high definition effect comes with uniform luminance and soft color is suitable for indoor close-range viewing.
7.Temperature: −20℃~+50℃.
Humidity:≤90%.MTBF:≥10,000 hours.Lifespan:≥50,000 hours.Defective Dot Rate: <0.0002.
