0.48kg High Resolution LED Screen , P2.5 Advertising Led Billboard
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE,ROHS,PSE,UL |
| Model Number: | P2.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | flight case |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
|
Detail Information |
|||
| Pixel Pitch: | P2.5RGB | Color: | FULL COLOR |
|---|---|---|---|
| Power: | 400 W/sqm | Drive Mode: | 1/32 Scan |
| Module Weight: | 0.48kg | LED Chip: | SMD2121 |
| Brightness: | 1200cd/sqm | Display Function: | Animation/Graphics/Video |
| High Light: | 0.48kg High Resolution LED Screen,0.48kg Advertising Led Billboard,P2.5 Advertising Led Billboard |
||
Product Description
Wall Mounted High Resolution LED Sigh P2.5 Advertising LED Billboard Screen SMD LED Module
Our Goal is to provide our customers with the best LED solutions for their needs,
with many years of LED Production experiences.
Add a welcome charming modern touch to your Advertising with this high-quality Led Sign!
led advertising message signs is widely used in shopping malls, hairdressers,
beauty chain stores, restaurants, bars, parking lots,
entertainment venues ect and suitable for all kinds of indoor and outdoor commercial billboards.
Module Specification:
| Dimensions(WxH) | 160x160mm | Resolution(WxH) | 64x64dots |
| Pixel Pitch(mm) | 2.5 | Pixel Density | 147456 pixels/m2 |
| Pixel Configuration | SMD 2121 | ||
| LED parameters |
R WL(620-625NM) IV:(600-800mcd) |
G: WL:(520-524nm) IV:(1400-1800mcd) |
B:WL:(470-472nm) IV :(800-880mcd) |
 |
|||
Cabinet Specification:
| Dimensions (WxH) | 480mm x 480mm | Module Quantity | 9 |
| Physical Resolution(WxH) | 192 x192 dots | Physical Pixels (Total) | 36864 |
| Weight/Cabinet | 8KG | Material | Die-Castiing aluminum |
|
|||
LED Display Parameter:
| Pixelpitch(mm) | P2.5 |
| LED Encapsulation | SMD2121 |
| Density(dot/m2) | 147456 |
| Module size LxH mm | 160*160mm |
| Module Resolution | 64*64dot |
| Cabinet Size | 480*480mm |
| Cabinet resolution | 192*192dot |
| Viewing Distance | 3-8m |
| viwe angle(H) | 140° |
| view angle(V) | 140° |
| Brightness (cd/m²) | 1500 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/16scan |
| MTBF | 100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| IP rating | IP55/IP42 |
Product Description
1) Simple and light structure in cabinet,easy in installation and maintation.
2) Adopting advanced world famous brand components in optical parts ,electric parts and operation parts.
3) Rigorous examination like age testing make sure that every piece of panel from our factory is extremely durable.
4) According to different request,we can customize our products and packages as you wish.
5) Excellent production and advanced software improve the visual feeling exceedingly.
Our service:
1.Providing professional technology supporting
2.Instructing installation and remote control
3.Trainning workers for free
4.Providing free procurement services
5.Customer first is our service tenet
FQA:
Q1. Can I have a sample order for the LED display?
A: Yes, we welcome sample order to test and check quality. Both for the module or the whole screen.
Q2. What about the lead time?
A: Order less than 100 square meters led time to take 15 working days
Q3. Do you have any MOQ limit for LED display order?
A: Low MOQ, 1 square meter or a module checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We mostly accept the FOB train term, but we can help you order and arrange a shipping agent. It usually takes 20 30 days on the sea. a few days for customs clearance
