900cd Indoor Advertising LED Display Screen CE ROHS PSE UL Certificate
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE,ROHS,PSE,UL |
| Model Number: | P2.5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | flight case |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
|
Detail Information |
|||
| Color: | Full Color RGB | Pixel Pitch: | P2.5 |
|---|---|---|---|
| Cabinet Size: | 480x480mm | Power Supply: | Meanwell |
| Brightness: | 500-900cd/sqm | Max Power: | 140 |
| Warranty: | 2 Years | Application:: | Indoor Advertising |
| High Light: | 900cd Indoor Advertising LED Display Screen,UL Indoor Advertising LED Display Screen,PSE LED Display Screen |
||
Product Description
Factory Price Video Wall P2.5 Indoor Front Maintenance LED Display Screen Cabinet For Indoor Advertising
DL LED is a professional LED Signs manufacturer for more than 10years history. Our LED Window Display Signs with high brightness, and user-friendly software including PC and APP version which makes you free to update the content everyday. The wireless LED scrolling sign would show the ultra bright text to help you attract your client eyes to increase business. Also our illuminated window signs is with UL certified power supply, which ensure the most durable quality for the LED Board .
Module Specification:
| Dimensions(WxH) | 160x160mm | Resolution(WxH) | 64x64dots |
| Pixel Pitch(mm) | 2.5 | Pixel Density | 147456 pixels/m2 |
| Pixel Configuration | SMD 2121 | ||
| LED parameters |
R WL(620-625NM) IV:(600-800mcd) |
G: WL:(520-524nm) IV:(1400-1800mcd) |
B:WL:(470-472nm) IV :(800-880mcd) |
 |
|||
Cabinet Specification:
| Dimensions (WxH) | 480mm x 480mm | Module Quantity | 9 |
| Physical Resolution(WxH) | 192 x192 dots | Physical Pixels (Total) | 36864 |
| Weight/Cabinet | 8KG | Material | Die-Castiing aluminum |
|
|||
LED Display Parameter:
| Pixelpitch(mm) | P2.5 |
| LED Encapsulation | SMD2121 |
| Density(dot/m2) | 147456 |
| Module size LxH mm | 160*160mm |
| Module Resolution | 64*64dot |
| Cabinet Size | 480*480mm |
| Cabinet resolution | 192*192dot |
| Viewing Distance | 3-8m |
| viwe angle(H) | 140° |
| view angle(V) | 140° |
| Brightness (cd/m²) | 1500 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/16scan |
| MTBF | 100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| IP rating | IP55/IP42 |
Product Description
1.160*160mm module with hign contrast pure black led lamp, which creates a perfect uniformity of screen and a better softness of color
2.PWM constant current drive and elimination drive, avoiding ghosts phenomenon, leading to a clear vision
3. ENIG of PCB welding plate and hign-performance gold plated connector, ensuring the oxidation resistance of module
4.8000:1 hign contrast ratio and 16 bit gray scale which shows a better color reduction
5. 480*480mm hign precision die-casting aluminum cabinet with a portable frame and a more smooth screen surface
6. alternative front-service die-casting aluminum cabinet with special installation tools which is available to front installation maintenance
7.available to all kinds of installation method, causing a more convenient and more stable installation
Package:
FQA:
Q1. Can I have a sample order for the LED display?
A: Yes, we welcome sample order to test and check quality. Both for the module or the whole screen.
Q2. What about the lead time?
A: Order less than 100 square meters led time to take 15 working days
Q3. Do you have any MOQ limit for LED display order?
A: Low MOQ, 1 square meter or a module checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We mostly accept the FOB train term, but we can help you order and arrange a shipping agent. It usually takes 20 30 days on the sea. a few days for customs clearance
