256x256 Dots High Resolution LED Screen Meanwell Power Supply
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE,ROHS,PSE,UL |
| Model Number: | P1.875 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | flight case |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
|
Detail Information |
|||
| Pixel Pitch: | P1.875 | Main Ic: | SMD 3IN1 1R1G1B |
|---|---|---|---|
| Driving Method: | 1/32 | Cabinet Size: | 480x480mm |
| Thickness: | 80mm | Usage: | Inside |
| Weight Of Cabinet: | 12kg | Power Supply: | Meanwell |
| Brightness: | 1000cd/sqm | Application: | Indoor Advertising |
| High Light: | 256x256 Dots High Resolution LED Screen,Meanwell Power High Resolution LED Screen,RoHS High Resolution LED Screen |
||
Product Description
Small Pixel Pitch P1.25 P1.56 P1.875 Fixed Installation Indoor HD Led Display Screen
LED screens and has a much wider viewing angle than the full color dip lamps LED screens. It rejects the deficiencies of the traditional LED lamp outdoor display screens.
LED Display Parameter:
| Indoor P2 LED Display | |
| Model number | P1.875 |
| Pixel pitch | 1.875mm |
| Module resolution | 128*128 |
| Module size | 240*240mm |
| Cabinet resolution | 256*256dots |
| Cabinet size | 480*480mm |
| LED configuration | SMD1515 |
| Brightness | ≥800cd/sqm |
| Module Weight | 0.25kg |
| Average consumption | 500w/sqm |
| View distance | 1.875m~200m |
| View angle | 140º |
| Pixel Density | 284442dots/M2 |
| Scanning | 1/32scan |
| Refresh rate | ≥1920Hz/3840Hz |
| Frame frequency | ≥360Hz |
| Max power consumption | 1000w/sqm |
| Warranty | 2years |
| Grey Scale | 16384 |
| Working voltage | 110/220VAC/50Hz±10% |
| Life span | 100000hours |
| Lifetime to 50% brightness | 75000hours |
| Working Temperature | −20℃ to +60℃ |
| Certification | CCC/CE/RoHS |
Product Description
1.240*240mm module with hign contrast pure black led lamp, which creates a perfect uniformity of screen and a better softness of color
2.PWM constant current drive and elimination drive, avoiding ghosts phenomenon, leading to a clear vision
3. ENIG of PCB welding plate and hign-performance gold plated connector, ensuring the oxidation resistance of module
4.8000:1 hign contrast ratio and 16 bit gray scale which shows a better color reduction
5. 480*480mm hign precision die-casting aluminum cabinet with a portable frame and a more smooth screen surface
6. alternative front-service die-casting aluminum cabinet with special installation tools which is available to front installation maintenance
7.available to all kinds of installation method, causing a more convenient and more stable installation
- High resolution of indoor full color LED display;
- Integrated encapsulation is blessed with higher reliability;
- Good color mixture from far or very near distance;
- Good color consistency transparent picture;
- Good picture uniformity;
- Wide viewing angle;
- Higher contrast ratio;
- The most economical and rational solution for 3 in 1 full color technology
Our service:
1.Providing professional technology supporting
2.Instructing installation and remote control
3.Trainning workers for free
4.Providing free procurement services
5.Customer first is our service tenet
FQA:
Q1. Can I have a sample order for the LED display?
A: Yes, we welcome sample order to test and check quality. Both for the module or the whole screen.
Q2. What about the lead time?
A: Order less than 100 square meters led time to take 15 working days
Q3. Do you have any MOQ limit for LED display order?
A: Low MOQ, 1 square meter or a module checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We mostly accept the FOB train term, but we can help you order and arrange a shipping agent. It usually takes 20 30 days on the sea. a few days for customs clearance
