High Resolution P3mm Programmable LED Signage With 5000mcd Brightness
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE/Rohs/PSE |
| Model Number: | P3RGB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box / flight box |
| Delivery Time: | 5-15days |
| Payment Terms: | L/C, T/T, Western Union, Credit Card, Visa |
| Supply Ability: | 500PCS/month |
|
Detail Information |
|||
| Features: | OPEN SIGN, Video Sign, Advertising Led Display | Product Name: | Outdoor LED Signs |
|---|---|---|---|
| Module: | P3 RGB LED | Pixel Pitch: | 3mm |
| Module Size: | 192*192mm | Brightness: | 5000mcd/㎡ |
| Power Consumption: | Max: 800W/㎡， Avrg: 300W/㎡ | Application: | Outdoor Waterproof IP65 |
| Working Voltage: | 110V/ 220V Wild Voltage Led By Switch | Life Span: | ≥100000hours |
| High Light: | P3mm Programmable LED Signage,IP65 Programmable LED Signage,P3mm Outdoor Digital Display Board |
||
Product Description
High Resolution P3mm Programmable LED Signage With 5000mcd Brightness
P3RGB High Resolution Outdoor Programmable LED Signage With 5000mcd Brightness
Features for LED Open Sign
1: High resolution: Distance for each led light is 3mm, there are 11,111 dots LED Lights for one square meter.
2: Clear effect and high refresh rate: P3 LED Module support 960, 1920, 3840 refresh rate.
3: Realiable quality: LED Billboard use nation star LED, Kinglight led, and brand IC.
4: UL certified power supply: Meanwell power supply, with wild votage, so it can be used both for 110V and 220V area.
5: Wireless programmable software, support phone APP, and with platform to release program
Specs for Outdoor Digital LED Signs:
| Name: | LED Module Sign |
| Pixel Pitch: | 3mm SMD1921 LED Dots |
| LED Block size: | 192*192mm |
| LED Light: | National star LED |
| Drive IC: | FM6126/MBI5124 |
| Driving mode: | 1/16 |
| Max power consumption per module: | 25W |
| LED Display size: | 636* 1020*75mm (25" * 40" * 3") |
| Brightness: | ≥5000mcd/㎡ |
| Program supported: | video, text, photo, optional for temperature, adjustable brightness |
| Working sytem: | WIN98,WINXP,WIN2000,Win7/8,etc |
| Customized size: | supported |
