High Brightness P5 RGB Outdoor Fixed LED Display 160*320mm Module
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE/Rohs/PSE |
| Model Number: | P5RGB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box / flight box |
| Delivery Time: | 5-15days |
| Payment Terms: | L/C, T/T, Western Union, Credit Card, Visa |
| Supply Ability: | 500PCS/month |
|
Detail Information |
|||
| Product Name: | Outdoor Fixed Led Display | Pixel Pitch: | 5MM |
|---|---|---|---|
| LED Light: | SMD 3in1 Kinglight 1820 Nation Star 1921 | Cabinet: | Steel Cabinet / Aluminum Cabinet |
| Module Size: | 160*320mm | Brightness: | ≥5000cd/㎡ |
| IP Grade: | Waterproof IP65 | Best Viewing Distance: | 5m-80m |
| High Light: | P5 RGB Outdoor Fixed LED Display,160*320mm Outdoor Fixed LED Display,P5 Outdoor LED Display |
||
Product Description
High Brightness P5 RGB Outdoor Fixed LED Display 160*320mm Module
Customized P5 RGB High Brightness Outdoor LED Display With 90° Video Showing LED Screen
LED Display with indoor and outdoor types. For outdoor LED Display, it should be with high brightness which should be visible under sunlight, and should be IP65 Waterproof. Nowadays the pixel pitch is popular for outdoor led screen: 10mm, 8mm, 6mm, 5mm, 4mm and 3mm. The smaller pixel pitch, the better video effect since it will be with higher resolution per square meter LED billboard.
Features of P5 LED Screen:
1: Pixel Pitch: 5mm SMD1921 LED Light, available for kinglight LED and national star LED
2: Cabinet: IP65 Waterproof design, steel cabinet, aluminum cabinet and galvanized plate.
3: Safety: Earth leakage circuit breaker has been used to ensure secure voltage protection
4: Air circulation exhaust window and cooling fan to provide a stable temperature for led board.
5: Communication interface: LAN, USB
6: Certified power supply: UL certified Meanwell , CL Power etc.
Specs of LED Walls:
| Item | Product Parameters | ||
| Product Model | P4 | P5 | P6 |
| Pixel Pitch | 4mm | 5mm | 6mm |
| LED Configuration | SMD1921 | SMD2727 / SMD3535 | SMD2727/ SMD3535 |
| Pixel Density | 62500dots | 40000dots | 27777dots |
| Module size | 256*128mm | 320*160mm | 192*192mm |
| Module resolution | 64*32dots | 64*32dots | 32*32dots |
| Cabinet Size | 512*512mm | 640*640mm | 576*576mm |
| Cabinet Resolution | 128*128dots | 128*128dots | 96*96dots |
| Scanning mode | 1/8 | 1/8 | 1/8 |
| Brightness | ≥5500cd/㎡ | ≥5500cd/㎡ | ≥5000cd/㎡ |
| Maintenance Mode | Back Maintenance | ||
| Life spane | ≥100,000hours | ||
