Wall Fixed Seamless P1.5 SMD2121 LED Ultra Slim Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE/Rohs/PSE |
| Model Number: | P2.5RGB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box / flight box |
| Delivery Time: | 5-15days |
| Payment Terms: | L/C, T/T, Western Union, Credit Card, Visa |
| Supply Ability: | 100square meters/month |
|
Detail Information |
|||
| Pixel Pitch: | 2.5mm | Module Size: | 160x160mm |
|---|---|---|---|
| Display Function: | Video, Picture, Graphics | LED Type: | SMD2121 |
| Power Consumption: | Avg.: 800W/㎡ | Brightness: | ≥1200cd/sqm |
| Viewing Angle: | H160/V160 | Screen Dimension: | Customized Size |
| High Light: | SMD2121 LED Ultra Slim Display,P1.5 Ultra Slim Display,P1.5 Seamless LED Screen |
||
Product Description
Ultra Slim Display Screens Smd Led Screen Wall Fixed Seamless Led Video Wall1.5 Pixel 2k 4k 16:9 Video Panel
Features:
1. Fully front service, fix it to the wall directly which saves space and installation time.
2. Wide color gamut, uniform color; 3840Hz high refresh rate, no tailing, ghosting phenomenon;
3. Natural heat dissipation, ultra-quiet and fanless design;
4. Die-cast aluminum design, CNC finishing, the cabinet flatness is very good;
5. NovaStar control system.
Product Specs:
| Pixelpitch(mm) | P2.5 |
| LED Encapsulation | SMD2121 |
| Density(dot/m2) | 147456 |
| Module size LxH mm | 160*160mm |
| Module Resolution | 64*64dot |
| Cabinet Size | 480*480mm |
| Cabinet resolution | 192*192dot |
| Viewing Distance | 3-8m |
| viwe angle(H) | 140° |
| view angle(V) | 140° |
| Brightness (cd/m²) | 1500 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/16scan |
| MTBF | 100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| IP rating | IP55/IP42 |
FQA:
Q1. Can I have a sample order for the LED display?
A: Yes, we welcome sample order to test and check quality. Both for the module or the whole screen.
Q2. What about the lead time?
A: Order less than 100 square meters led time to take 15 working days
Q3. Do you have any MOQ limit for LED display order?
A: Low MOQ, 1 square meter or a module checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We mostly accept the FOB train term, but we can help you order and arrange a shipping agent. It usually takes 20 30 days on the sea. a few days for customs clearance
