Dustproof Led Display Board For Advertising CE RoHs FCC certificate
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE, ROHS,UL,FCC,PSE |
| Model Number: | 6RGB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Wooden Package |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 500pc/Month |
|
Detail Information |
|||
| Pixel Pitch: | Pitch 6mm | Driving Method: | 1/8 Scan |
|---|---|---|---|
| Model Number: | SMD3535 | Power Supply: | Meanwell |
| Viewing Angle: | 140H,120V | Module Size: | 192X256mm |
| Certificate: | CE,RoHs,FCC | Display Function: | Video,image |
| High Light: | Dustproof Led Display Board For Advertising,FCC Led Display Board For Advertising,RoHs FCC led display for advertising |
||
Product Description
High Brightness P4 P5 P6 P8 P10 Indoor/Outdoor Led Display Advertising Led Screen
LED display,also called led screen, led video wall, or led sign, with its unique advantages,has gradually replaced the traditional billboards, light boxes,etc. LED display advertising has become a new force in the media industry.
Traditional advertising can only show pictures, But LED display/led video wall/led screen can perfect combine text, pictures, video, and sound with high resolution,high brightness and full color! LED display Advertising screen can easily attract the attention of pedestrians,and also are easy to remember,which can generate greater advertising effectiveness.
Feature
* Dustproof and Waterproof IP68
* Anti-Flaming Performance
* Aluminum Cabinet Compares with Iron Cabinet Available for choose
* Common Cathode Aluminum Display: Energy-Saving by 75%
* Zinc Alloy Edge Lock Design, Easily Front and Rear Maintenance
* There are 4 configuration schemes for option, common cathode is a new technology to save energy, the pixel pitch is P6.67, P8 and P10 for option.
LED Display Parameter
| Item | Technical parameter | |
| Panel | Dimension | (W)192mm*192mm(H) |
| Pixel pitch | 6mm | |
| Pixel Density | 27777dots/ M2 | |
| Pixel configuration | 1R1G1B | |
| LED specification | SMD3535 | |
| Pixel resolution | (W)32 dots*32dots(H) | |
| Average power | 10W | |
| Panel weight | 0.37KG | |
| Cabinet&Bracket | Cabinet size | 960mm*960mm |
| Quantity of panel | 27.126PCS/M2 | |
| Best viewing angle | H:>170 V:>120 | |
| Best viewing distance | 6-100M | |
| Working temperature | -25 -- +55 | |
| Panel power supply | 5V40A | |
| Screen power supply | AC220V—AC250V | |
| Max power | 600W/M2 | |
| Average power | 300W-500W/M2 | |
| Technical parameter | Driving device | 16206 Constant current drive |
| Drive type | 1/8 Scanning | |
| Refresh frequency | 1920HZ/S | |
| Display color | 4096*4096*4096 | |
| Brightness | 6000-7000cd/ M2 | |
| Life span | 100000Hours | |
| Communication distance | 100M | |
FAQ:
Q2: Where is it used for?
A2: Indoor & rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
