Product Details:

Place of Origin: CHINA
Brand Name: DL
Certification: CE, ROHS,UL,FCC,PSE
Model Number: P6RGB

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: Negotiate
Packaging Details: Wooden Package
Delivery Time: 5-15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500pc/Month
Get Best Price Contact Now

Detail Information

Pixel Pitch: 6mm Driving Method: 1/8 Scan
Panel Size: 192*192mm Resolution: 32dots(W)*32dots(H)
Pixel Density: 27777dots/m2 Brightness: 5500nit
Color: Black Model Number: Outdoor P6 Module
Panel Weight: 0.35KG Life Span: 100000hours
High Light:

0.35KG P6 Outdoor Led Module

,

SMD3535 Outdoor Led Module

,

Commercial Display smd led module

Product Description

2021 Factory Price Customized Outdoor P6 Led Screen Module For Commercial Display

Product Feature:
1) Front or rear maintenance option, realizing module, power supply and receiving card front or rear maintenance, saving your maintenance cost.

2) Adopt top high brightness with low power consumption LED lamp,energy saving≥30%, if adopt 28 kinds of main patent technique, entire energy saving ≥50%, environment protection.Pioneer in outdoor mature HD LED Display, all advanced specifications 2 years earlier than others, successful cases around the world.

3) Free back service path for all kinds of installation surroundings.Broadcast level color scale, color temperature and brightness adjustable intelligentizedly, smooth color, high color ratio, nature pictures.

4) It can be curved into different shape to fit convex or concave wall or rugged wall or building, and it can be shaped into column to wrap pillars for animation decoration.



 LED Display Parameter

Item Technical parameter
Panel Dimension (W)192mm*192mm(H)
Pixel pitch 6mm
Pixel Density 27777dots/ M2
Pixel configuration 1R1G1B
LED specification SMD3535
Pixel resolution (W)32 dots*32dots(H)
Average power 10W
Panel weight 0.37KG
Cabinet&Bracket Cabinet size 960mm*960mm
Quantity of panel 27.126PCS/M2
Best viewing angle H:>170 V:>120
Best viewing distance 6-100M
Working temperature -25 -- +55
Panel power supply 5V40A
Screen power supply AC220V—AC250V
Max power 600W/M2
Average power 300W-500W/M2
Technical parameter Driving device 16206 Constant current drive
Drive type 1/8 Scanning
Refresh frequency 1920HZ/S
Display color 4096*4096*4096
Brightness 6000-7000cd/ M2
Life span 100000Hours
Communication distance 100M



0.35KG SMD3535 Outdoor Led Module For Commercial Display 00.35KG SMD3535 Outdoor Led Module For Commercial Display 1

0.35KG SMD3535 Outdoor Led Module For Commercial Display 20.35KG SMD3535 Outdoor Led Module For Commercial Display 30.35KG SMD3535 Outdoor Led Module For Commercial Display 40.35KG SMD3535 Outdoor Led Module For Commercial Display 5



* Seamless splice: Completely seamless splicing without any visual black seam.
* Screen calibration: Gamma correction technology to realize brightness and color correction point by point.
* Intelligent light control: Intelligent adjusting brightness to improve image comfort level and save more power.
* Oversized view: Super wide view, larger display visual scope, the picture remains clear at any angle.
* Heat dissipation: Unique heat dissipation technology, more secure in using with longer lifetime.
* Remote control: Remote control screen with more convenient operation.
*Extensive use: It is capable to play video, picture and text.
*IP65:Good protective property to avoid any environmental influence to the service life from the dust, rain etc,meeting the demands of outdoor applications;
* Input Voltage:AC100-220V;


0.35KG SMD3535 Outdoor Led Module For Commercial Display 6

FQA:

Q1. Can I have a sample order for the LED display?

A: Yes, we welcome sample order to test and check quality. Both for the module or the whole screen.

Q2. What about the lead time?

A: Order less than 100 square meters led time to take 15 working days

Q3. Do you have any MOQ limit for LED display order?

A: Low MOQ, 1 square meter or a module checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We mostly accept the FOB train term, but we can help you order and arrange a shipping agent. It usually takes 20 30 days on the sea. a few days for customs clearance
