1024x1024mm Led Video Display Board P8 / P10 Fixed Installation for outdoor
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE, ROHS,UL,FCC,PSE |
| Model Number: | P8RGB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Wooden Package |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 500pc/Month |
|
Detail Information |
|||
| Pixel Pitch: | Pitch 8mm | Driving Method: | 1/2 Scan |
|---|---|---|---|
| Model Number: | SMD | Power Supply: | Meanwell |
| Viewing Angle: | 140H,120V | Panel Size: | 1024mmx1024mm |
| Certificate: | CE,RoHs | Display Function: | Video |
| High Light: | Fixed Installation Led Video Display Board,1024x1024mm Led Video Display Board,1024x1024mm led display board outdoor |
||
Product Description
Outdoor Fixed Installation P8 /P10 Full Color Video Led Display Board
P5/P6/P8/P10 outdoor LED screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine. It can be assembled and disassembled very easy, and it is an ideal product for any kind advertisements.
Product Description:
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale,achieving the debugging technology for nice image.
LED Display Parameter
| Pixelpitch(mm) | P8 |
| LED Encapsulation | CREE SMD3535 |
| Density(dot/m2) | 15625/sqm |
| Module size LxH mm | 256*128mm |
| Module Resolution | 32*16dot |
| Viewing Distance | 8-20m |
| viwe angle(H)- (V) | 120°- 120° |
| Brightness (cd/m²) | 7200 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/8scan |
| MTBF | ﹥100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| Color temperature | 6500K |
| IP rating | IP65/IP55 |
| Signal input format | Composite, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
Main advantages:
1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;
2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;
3. Module surface flatness ± 0.2mm, the entire screen has good flatness;
4.High uniformity display color;
5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.
6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;
7. Using fishbone bus line greatly reduces the contact problem;
8. IP65 grade for high performance waterproof and dustproof capability;
9. -25°C – 65°Cworking environment for outdoor display, adapted to the harsh environment.
Packing:
FAQ:
Q2: Where is it used for?
A2: Indoor & rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
