Iron cabinet 1024x1024mm Led Wall Outdoor Display 14400 Physical Pixels
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE, ROHS,UL,FCC,PSE |
| Model Number: | P8RGB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiate |
| Packaging Details: | Wooden Package |
| Delivery Time: | 5-15days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 500pc/Month |
|
Detail Information |
|||
| Pixel Pitch: | P8/P10/P12/P16 | Cabinet Material: | Iron Cabinet |
|---|---|---|---|
| LEDs: | SMD3535 | Power Supply:: | Meanwell/G-enery |
| Brightness: | 6000nits | Warranty: | 36 Monthes |
| Dimension: | 1024mmx1024mm | Viewing Angle: | 140H,120V |
| High Light: | 1024x1024mm Led Wall Outdoor Display,14400 Pixels Led Wall Outdoor Display,1024x1024mm outdoor advertising led |
||
Product Description
Outdoor Advertising Led Large Screen Display P8 Led Video Screen
P8/P10/P16 outdoor led screen adopts physical and virtual pixel technology which makes the picture more clear and vivid, no flicker and blind dots. The screen is manufactured in a waterproof and dustproof design so it can work very well in rain and sunshine. It can be assembled and disassembled very easy, and it is an ideal product for any kind advertisements.
Cabinet Specification:
| Dimensions (WxH) | 960mm x960mm | Module Quantity | 18 |
| Physical Resolution(WxH) | 120 x 120 dots | Physical Pixels (Total) | 14400 |
| Weight/Cabinet | 50KG | Material | Iron/Aluminum |
Flexible Designing:
Cabinet design standardized makes the same cabinet dimension applicable to different requirements of display pixels, make installation for advertising screens more convenient. Reasonable circuit wiring makes the quality stability and reliability. The fans inside the unit cabinet can accelerate cooling.
Trouble-free & Maintenance with ease:
Excellent material and workmanship guarantee its quality and dependability, trouble-free for 3~5 years.
Humanized design makes cabinet, modules easy to maintain without tools.
LED Display Parameter
| Pixelpitch(mm) | P8 |
| LED Encapsulation | CREE SMD3535 |
| Density(dot/m2) | 15625/sqm |
| Module size LxH mm | 256*128mm |
| Module Resolution | 32*16dot |
| Viewing Distance | 8-20m |
| viwe angle(H)- (V) | 120°- 120° |
| Brightness (cd/m²) | 7200 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/8scan |
| MTBF | ﹥100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| Color temperature | 6500K |
| IP rating | IP65/IP55 |
| Signal input format | Composite, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale,achieving the debugging technology for nice image.
Packing:
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
