CREE SMD3535 Sports Perimeter LED Display Fixed Installation PSE approval
CREE SMD3535 Sports Perimeter LED Display
,PSE Sports Perimeter LED Display
,CREE SMD3535 stadium perimeter led display
Multifunction P8 P10 Fixed Installatiion Rental Usage Sports Perimeter LED Display
Cabinet Specification:
| Dimensions (WxH) | 960mm x960mm | Module Quantity | 18 |
| Physical Resolution(WxH) | 120 x 120 dots | Physical Pixels (Total) | 14400 |
| Weight/Cabinet | 50KG | Material | Iron/Aluminum |
LED Display Parameter
| Pixelpitch(mm) | P8 |
| LED Encapsulation | CREE SMD3535 |
| Density(dot/m2) | 15625/sqm |
| Module size LxH mm | 256*128mm |
| Module Resolution | 32*16dot |
| Viewing Distance | 8-20m |
| viwe angle(H)- (V) | 120°- 120° |
| Brightness (cd/m²) | 7200 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/8scan |
| MTBF | ﹥100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| Color temperature | 6500K |
| IP rating | IP65/IP55 |
| Signal input format | Composite, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
Main advantages:
1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;
2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;
3. Module surface flatness ± 0.2mm, the entire screen has good flatness;
4.High uniformity display color;
5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.
6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;
7. Using fishbone bus line greatly reduces the contact problem;
Packing:
-
