320*160mm Led Outdoor TV Billboard , 60Hz Video Wall Display Panels
320*160mm Led Outdoor Tv Billboard
,320*160mm Video Wall Display Panels
,320*160mm 60Hz Video Wall Display Panels
Led Outdoor Tv Billboard Led Sign Board P8 P10 Led Mobile Advertising Trucks For Sale
DL LED is a professional LED Signs manufacturer for more than 10years history. Our LED Window Display Signs with high brightness, and user-friendly software including PC and APP version which makes you free to update the content everyday. The wireless LED scrolling sign would show the ultra bright text to help you attract your client eyes to increase business. Also our illuminated window signs is with UL certified power supply, which ensure the most durable quality for the LED Board.
Cabinet Specification:
| Dimensions (WxH) | 960mm x960mm | Module Quantity | 18 |
| Physical Resolution(WxH) | 96 x 96 dots | Physical Pixels (Total) | 9216 |
| Weight/Cabinet | 50KG | Material | Iron/Aluminum |
LED Display Parameter
| Pixelpitch(mm) | P10 |
| LED Encapsulation | SMD3535 |
| Density(dot/m2) | 10000/sqm |
| Module size LxH mm | 320*160mm |
| Module Resolution | 32*16dot |
| Cabinet Size | 2240mm x 1440mm |
| Cabinet resolution | 224*144dot |
| Viewing Distance | 10-20m |
| viwe angle(H) - (V) | 140°- 140° |
| Brightness (cd/m²) | 6000 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/4scan |
| MTBF | ﹥100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| IP rating | IP65/IP55 |
| Signal input format | Composite, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
Main advantages:
1. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect;
2. The cabinet of unit modules adopts to high-temperature spraying technology, the antirust function is greatly improved;
3. Module surface flatness ± 0.2mm, the entire screen has good flatness;
4.High uniformity display color;
5. For improving the service life, PCB is made by wave soldering process with the green oxygen isolation layer, which prevents the line of moisture and oxidation.
6. Service efficiency of the screen switch power supply is increased substantially, which reduces power failure rate;
7. Using fishbone bus line greatly reduces the contact problem;
Packing:
-
