P2 RGB Indoor Fixed LED Screen 128x256mm For Stage Background
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | DL |
| Certification: | CE/Rohs/PSE |
| Model Number: | P2RGB |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box / flight box |
| Delivery Time: | 5-15days |
| Payment Terms: | L/C, T/T, Western Union, Credit Card, Visa |
| Supply Ability: | 100square meters/month |
|
Detail Information |
|||
| Pixel Pitch: | 2mm | Module Size: | 128*256mm |
|---|---|---|---|
| LED Type: | Kinglight SMD1515 | Scanning Mode: | 1/32 Scanning |
| Lifetime: | 100,000hours | IP Level: | IP30 |
| Grey Scale: | 16bits | Input Power Frequency: | 50/ 60Hz |
| Operating Environment: | Temperature: -10°C～60°C; Humidity: 10%～90% | Input Voltage (AC): | 220~240V/AC(±10%) Or 110V /AC |
| High Light: | P2 RGB Indoor Fixed LED Screen,128x256mm Indoor Fixed LED Screen,128x256mm led screen p2 |
||
Product Description
P2 RGB HD Video Wall indoor fixed LED Screen for stage background with Novastar controller
Display Labs company is a globally leading LED advertising display supplier based in Shenzhen, China. From outdoor
to indoor, we are provide P10RGB, P8, P6, P5 P4, P3, P2.5, P2, P1.875 etc pixel pitch LEDs. For indoor LED Wall, since
the limited viewing distance and video program required, P1.875 and P2RGB LED Module would be the perfect solution.
With several pcs cabinet, they can be joint into different size LED Screens to meet different requirements.
Features:
1: DIY Size, cabinet with standard 512*512mm, several pcs can joint into one LED Display.
2: Vivid content showing, wireless transmission.
3: Energy saving LED and long life UL certified Meanwell power supply.
4: 2 years warranty and life time free technical support.
5: Soft LED and long life span, up to 100000hours life time.
Product Specs:
| Model: | P2RGB LED Wall |
| Pixel Pitch: | 2mm |
| Pixel Density: | 250,000pixles one square meter |
| Module Size: | 128*256mm |
| Cabinet size: | 512*512mm |
| LED Type: | SMD1515 3in1 |
| Life Span Time: | ≥100,000hours |
| Viewing Angle: | 120° (horz.), 60° (vert.) |
| Best Viewing Distance: | 2 - 27m |
| Driving method: | 1/32 scanning mode |
| Grey scale: | 16bits |
| Interface: | Standard Ethernet |
| Video input(w/video processor): | DVI, HDMI, PAL/NTSC/SECAM;S-Video;VGA;Composite etc. |
| Input voltage (AC): | 220~240V/AC(±10%) or 110V /AC |
| Transmission distance: | Sychronous system: Basic internet cable ＜100m, Asychronous System: <300m, ( Fiber Optional) |
Service Provided:
1: Professional suggestion based on client’s requirements.
2: Prepare quotation and arrange drawing.
3: In time update during production.
4: 2years warranty, Lifetime free technical support and upgrade.
FAQ:
A1: If connect with HDMI Cable, can we divide the LED display to show two different content?
Q1: The video processor can be set to divide the whole screen to 2parts from up to down, right to left.
A2: How to do the connection for several pcs cabinet indoor LED video display?
Q2: We will provide the document with clear drawing connection for power cable and data cable.
A3: Which controller used for the wedding LED Screen?
Q3: Normally we use HD controller, Novastar controller for our indoor LED signs, if need other brand, please talk with
us before production.
